Bringing Pressure Pumping Services to Grande Prairie and Beyond

Boreal Pumping is dedicated to bringing expert pressure pumping solutions to energy producers in Grande Prairie and the wider area. We are committed to saving our clients time and money. From fluid pumping to nitrogen services, we’ve got you covered.

Our team of specialists has brought peace of mind to businesses in northern Alberta and north-eastern British Columbia through our full spectrum of stimulation services. With superior technology and seasoned personnel, we are your local industry leader for pumping services and wellbore issue solutions.

Boreal Pumping Truck

Our qualified Grande Prairie-based team provides our clients with a diverse group of pumping services and top-class pumping stimulation services. We’re equipped with years of experience, custom-designed equipment, and tried-and-true products.

Our Services

Services


Pump Down Support

Our pump down support allows you to pumping two types of fluid simultaneously between the wellbore and backside for ultimate utilization - all while cutting costs. Our units are specifically designed for single or multi-well pump down operations; however, they are incredibly versatile in their application. Clients also use these spreads for preliminary pad work, such as pressure testing wellhead, testers lines, stump tests, opening toes and spearheading acid prior to frac date.

Nitrogen Pumping

We are equipped with five 85 scm/min non-fired nitrogen pumps, along with one bulk nitrogen trailer that can haul 20,000 scm of nitrogen. Our nitrogen services provide pipeline pigging, purge and suspension, N2 blankets, sand clean outs, and displacing of wellbore fluids and pressure testing.

Fluid Disposal

Oilfield fluids must be disposed of into a permitted disposal well and is often the second-largest expense of drilling and completing a new well in Alberta. The need of disposing water produced in association with oil and gas is a constant battle every customer faces. Boreal can provide the necessary rate for your disposal needs to keep your operations moving.

Diagnostic Fracture Injection Testing

A DFIT is a is a small volume of fluid injected at a low test rate, in order to create a fracture, followed by an extended fall-off period. DFITS are also referred to as a mini-frac, data-frac or g-function test. DFITs are a method for estimating reservoir parameters for low permeability reservoirs that would otherwise not flow prior to fracturing. The DFIT provides a practical tool to characterize the reservoir and hydraulic fracture parameters with results inclusive of reservoir pressure, permeability, fracture gradient, fracture pressure, fluid efficiency and deviatory stress possibility. Apart from the permeability and pressures data quality, DFIT provides accurate fracturing data which will be integrated with reservoir parameters for successful hydraulic fracture.

Step Rate Injection Testing

A Step Rate Injection Test is performed in preparation for a frac in which fluid is injected for a defined period through a series of increased pump rates. The resulting data is used to identify key parameters of the fracturing operation, such as the pressure and flow rates required to successfully complete the frac treatment.

Acid Pumping

Acidizing is performed in an effort to restore the natural permeability of the reservoir rock. Well acidizing is achieved by pumping acid into the well to dissolve limestone, dolomite and calcite cement between the sediment grains of the reservoir rocks. There are two types of acid treatment: matrix acidizing and fracture acidizing.

Equipment


Pump Down Spreads with Backside Monitoring

What sets us apart? We have the largest range of fluid pumping rates in the province. We also offer single- or multi-well backside support with live/remote monitoring, so there is no need for a pressure truck or vacuum truck.

Boreal Pumping Trucks

Our pump down spread units are the only high pressure/high volume units with simultaneous backside support on the market, providing the horsepower of a frac pump (2500 HHP) and the precision of a low-volume pressure truck with our LVHP jet pump.

Pump down spread specifications:

  • Rates redundant up to 1.5m3/min at 70 mPa
  • As low as 0.25l/min at 103 mPa
  • Complete sling restraint systems
  • 2” and 3” 1502 Integral 15,000 Psi iron
  • On-the-fly chemical systems with heated trailer
  • Live link data watching capability (Cell service Required)

What Sets Us Apart

  • We have the largest range of fluid pumping rates in the province
  • Single or multi-well backside support with live/remote monitoring so there is no need for a pressure truck
  • No vacuum truck required
  • Fully integrated chemical system

Acid Pumpers

Our fleet is outfitted with four state-of-the-art acid fluid trucks, enabling us to complete acid squeezes, selective acid jobs, nitrified acid jobs, acid matrix, ball launching, backside monitoring and pressure testing.

Boreal Pumping Trucks

Acid pumping truck specifications:

  • Equipped with an 8 m3 fiberglass tank (5 m3 + 3 m3 compartment)
  • Capable of pumping 0.15 -1100 liters per minute at up to 15,000 Psi
  • Capable of legally hauling up to 1 m3 of acid
  • Control cabin allows for monitoring of engine diagnostics, fluid rates and pressures by providing PDF and CSV reporting to our clients
  • Equipped with a low-volume-high-pressure jet pump, capable of producing rates as low as 0.15l/min at 15,000 Psi

N2 Pumpers

Field-proven design with leading edge technologic integrations makes Boreal’s N2 pumpers industry leaders.

Flow rates from 5-70 scm per minute at pressures up to 69 mpa.

Features:

600 Total Horsepower Output

  • (1) Cummins ISX 600 power supply rated 600 bhp

250 Total hydraulic horsepower output

  • (1) Nov NP-200 10k (69 mpa) triplex pump rated at 250 hhp with 250 bhp input

Fully integrated data acquisition system

  • Instantaneous value recording and graphing
  • Real-time data streaming — remote well monitoring
  • Full redundancy to eliminate data failures
  • Flameless glycol heat recovery system
  • 7500 scm cryogenic spec tank
N2 Pumper Operator Compartment

Fluid Pumpers

A tried and tested platform with the latest technological advances making Boreal’s single pumpers the industry leaders.

Flow rates from 1-1200 liters per minute at pressures up to 103 mpa. 1200 lpm @ 13 mpa — 220 lpm @ 103 mpa.

Features:

600 Total horsepower output

  • (1) Cummins ISX 600 power supply rated 600 bhp

600 Total hydraulic horsepower output from 2 pumps

  • (1) Gardner Denver 10 & 15k (103 mpa) pump 50 hhp
  • (1) SPM TWS 600 10 & 15k (103 mpa) triplex pump rated at 600 hhp with 550 bhp input

Fully integrated data acquisition system

  • Instantaneous value recording and graphing
  • Coriolis style flow meters accurate down to 5 ml
  • Real-time data streaming – remote well monitoring
  • Full redundancy to eliminate data failures

On board, traceable chemical injection system

  • Coriolis metered, operator controlled
  • Allows for accurate placement of treatment chemicals
  • Heated support unit contains full array of gels, friction, reducers & methanol
  • Suction piping injection & batch mixing capabilities
Boreal Pumping Equipment

Fully redundant suction piping

  • Eliminates down time due to failures
  • Designed with gear pump inline to allow for easy fluid
  • Transfer and removal of treating iron under vacuum
  • Eliminates third party charges
  • Dot compliant chemical delivery

8M3 DUAL COMPARTMENT SPEC TANK

  • Dot compliant chemical delivery

Twin Fluid Pumpers

Boreal Twin Fluid Pumpers

These state of the art units set the new standard in North America, offering the highest safety and performance on the market.

Flow rates from 1-3000 liters per minute at pressures up to 103 mpa. 3000 lpm @ 14 mpa — 770 lpm @ 103 mpa.

Features:

2100 Total horsepower output from three engines

  • (1) Cat C9 auxiliary power supply rated 400 bhp
  • (2) Cat C18 direct drive prime movers rated 1700 bhp

1800 Total hydraulic horsepower output from 3 pumps

  • (1) Gardner Denver 15k (103 mpa) jet pump 100 hhp
  • (2) SPM QWS 1000 15k (103 mpa) quintuplex pumps rated at 1000 hhp each with 850 bhp input totaling 1700 hhp

Fully integrated data acquisition system

  • Instantaneous value recording and graphing
  • Coriolis style flow meters accurate down to 5 ml
  • Real-time data streaming — remote well monitoring
  • Full redundancy to eliminate data failures

On board, traceable chemical injection system

  • Coriolis metered, operator controlled
  • Allows for accurate placement of treatment chemicals
  • Heated support unit contains full array of gels, friction, reducers & methanol
  • Suction piping injection & batch mixing capabilities

Fully redundant suction piping

  • Eliminates down time due to failures
  • Designed with gear pump inline to allow for easy fluid transfer and removal of treating iron under vacuum
  • Eliminates third party charges

Management Team


Darryl Smith - Operations Manager

Darryl is responsible for the operations and expansion of the Boreal Pumping group to continue it’s dedicated service to our loyal customers. He joined Bonnetts in July 2015 as the Operations Support Manager of Boreal Pumping and was offered the position of Operations Manager in January of 2017 which he continues to hold today.

Prior to Bonnetts, Darryl started in the Fracturing world where he spent 14 years with companies such as Trican, Calfrac and Sanjel.

CONTACT  780-513-3400 | 780-518-1708 | dsmith@bonnettsenergy.com


Shaun Kristianson - Operations Support Manager

Shaun started his career pumping cement and acid with Sanjel Corp. in 2000 and continued that path with Calfrac Well Services until 2010 at which time he changed focus to Coiled Tubing eventually leading him into a dispatch roll. Shaun joined the Bonnetts team in 2016 starting in the field until he was promoted to Operations Support Manager for Boreal Pumping.

CONTACT  780-513-3400 | 780-518-1708 | skristianson@bonnettsenergy.com
